Voltage Grade |
10kV,35kV,66kV,110kV,132kV,220kV,330kV,500kV |
Raw Material |
Steel Q235,Q235,Q345,Q355,Q420,Q460 or Customed |
Surface Treatment |
Hot dip galvanized |
Galvanized Thickness |
Average layer thickness 86um |
Painting |
Customized |
Manufacturing Standard |
GB/T2694-2018 |
Raw Material Standards |
GB/T700-2006,IS0630-1995,GB/T1591-2018;GB/T706-2016; |
Design Code |
1. Chinese National Standard: a. DL/T 5154-2002 Technical Regulation of Design For Tower and Pole Structuresof Overhead Transmission Line b. DL/T 5219-2005 Technical Regulation for Designing Foundation of Overhead Transmission Line 2.American Standard: a. ASCE 10-97-2000 Design of Latticed Steel Transmission Structuresb. ACl 318-02 Building Code Requirement for Structure Concrete |
Design Loading |
As per requirement and specification by Clients worldwide. |
Load test/destructivetest |
We can arrange it by Government authority if it is necessary and the cost of such kind of test is separately from the tower |
Hot-dip galvanization |
ISO 1461-2009, ASTM A123 |
